SIHGA® SymbioFix® SFT

Cork interlayer as protection for flat roof foils protects against mechanical damage to the sealing level does not contain any plasticisers prevents a plasticizer migration between flat roof foil and adjustable feet optimal for adjustment feet JustiFix® JK (II) made of chemically neutral material cork is resistant to moisture, does not rot and is resistant against most acids cork as a flexible material inhibits impact sound, noise-insulating is non-slip and pressure-stable

Prevents direct contact of the supporting structure to the foundation. To eliminate waterlogging of JustiFix® II JM provides valuable assistance. At the same time it saves a lot of work, because the height adjustment can be carried out not only from below (with spanner SW 10) but also easily from the top (with a screwdriver). Thereby, the fast and accurate mainly level orientation of the substructure is guaranteed on the foundation.The JustiFix® II JM is articulated in the weatherproof Kunststoffdämmelement, whereby he adapts very well to existing unevenness and increases walking comfort on the terrace with its vibration damping effect.Application on solid groundJM 40: height adjustment 25 - 40 mmJM 60: height adjustment 25 - 60 mmJM 80: height adjustment 25 - 80 mmThe recommended load per JustiFix® II JM is 1.20 kN. The exhibit compressive strength of insulation must be at least. 0.05 N / mm2 (50 kPa).The amount needed per m2 depends on the dimension of the substructure, often 4 pieces per m2 are installed, for example, at 600 mm spacing of the substructure.

It is essential for the durability of terraces is that the planks (decking) are infringed neither at the top nor at the lateral edges - exactly these important conditions are met the DielenFix®. His height of 6 mm ensures perfect constructive wood protection to the substructure and ensures optimally ventilating tete terrace - an essential criterion for the life of terraces. The enclosed SIHGA Bohrfix system screws for fastening to the substructure are specially manufactured without drilling for mounting on aluminum or wood and have a length of 29 mm. SIHGA DielenFix quantity calculation:To determine the amount required, we recommend the following auxiliary formula:Total linear meters of the substructure / plank width including gap x 2Using the example of a terrace with a 15 meter substructure, hallway width 144 mm, 6 mm groove:15 / 0.150 x 2 = 200 pieces    The use: fastened planks not visible screwed; produced, developed and patented in Austria gives elegant appearance and safety of the screw suitable for almost all types of wood reduces errors on site upon delivery of the material; thereby bringing time savings and reduced storage costs Made of SIHGAMID®, the fiberglass-reinforced plastic from the Space Exploration secured more durable than stainless steel, even when säurehältigen woods; is extremely strong, heat, frost and UV-resistant; no material fatigue Floorboards remain intact at all visible surfaces the woods are screwed from below, which gives longer shelf life and prevents putrefaction and the direct influence of weather like swelling and shrinkage of the wood from operations reduces the crack and fracture behavior of wood in these natural processes Choice of three screw lengths Possible use for all common hallway strengths 19-40 mm variable visible joint 0-15 mm, for each suitable builders Height, material thickness 6 mm for optimum aeration and ensures optimum constructive wood protection at DielenFix® II DF CS A4 screws are enclosed time-saving, convenient, accurate and matching SIHGAFIX® prevents rust and rust and stainless steel A4 BohrFix® for saltwater and chlorine environment Included SIHGAFIX® stainless, hardened stainless steel BohrFix® with drill bit and installation instructions no rust, no tearing or rupture of the screws; time-saving, convenient, accurate, all accessories accompanies SIHGA® TIP: MAGBIT® facilitates assembly For optimum adaptation to the type of wood of the boards or on the weathering situation of DielenFix® is produced in different materials or equipped with different fastening screws:Type DielenFix® II DF incl. BohrFix® stainless steelType DielenFix® II DF CS incl. BohrFix® stainless steel A4Type DielenFix® DF incl. BohrFix® stainless steel
