DILA2 Universal Decking Connector

SIHGA GleitFix is a further development of the SIHGA DielenFix.The successor to the DielenFix is a one-part system, which is fastened to the underside of the floor with three screws. The clip connection between the two glass fiber reinforced plastic plates facilitates the alignment of the fastening. Compared to the DielenFix, the system saves a stainless steel drill screw per attachment. SIHGA GleitFix can be used for nearly all types of wood with a width between 90 and 150 mm.Its height has been raised from 6 to 8 mm, which ensures perfect structural protection for the substructure and guarantees an optimal aerated terrace - a key criterion for the service life of terraces.Also new is a special attachment for the initial and end boards. Now these can also be fixed invisibly: GleitFix AE SIHGA DielenFix quantity calculation:To determine the amount required, we recommend the following auxiliary formula:Total linear meters of the substructure / plank width including gapUsing the example of a terrace with a 15 meter substructure, hallway width 144 mm, 6 mm groove:15 / 0.150  = 100 pieces The use: fastened planks not visible screwed; produced, developed and patented in Austria gives elegant appearance and safety of the screw suitable for almost all types of wood reduces errors on site upon delivery of the material; thereby bringing time savings and reduced storage costs Made of SIHGAMID®, the fiberglass-reinforced plastic from the Space Exploration secured more durable than stainless steel, even when säurehältigen woods; is extremely strong, heat, frost and UV-resistant; no material fatigue Floorboards remain intact at all visible surfaces the woods are screwed from below, which gives longer shelf life and prevents putrefaction and the direct influence of weather like swelling and shrinkage of the wood from operations reduces the crack and fracture behavior of wood in these natural processes Choice of three screw lengths Possible use for all common hallway strengths 19-40 mm variable visible joint 0-15 mm, for each suitable builders Height, material thickness 8 mm for optimum aeration and ensures optimum constructive wood protection at GleitFix® GF CS A4 screws are enclosed time-saving, convenient, accurate and matching SIHGAFIX® prevents rust and rust and stainless steel A4 BohrFix® for saltwater and chlorine environment Included SIHGAFIX® stainless, hardened stainless steel BohrFix® with drill bit and installation instructions no rust, no tearing or rupture of the screws; time-saving, convenient, accurate, all accessories accompanies SIHGA® TIP: MAGBIT® facilitates assembly For optimum adaptation to the type of wood of the boards or on the weathering situation of DielenFix® is produced with different fastening screws:Type GleitFix® GF incl. BohrFix® stainless steelType GleitFix® GF CS incl. BohrFix® stainless steel A4

BASO is a spacer for ventilation and prevents waterlogging between the decking and the substructure. The integrated glass fiber reinforced spring elements contribute to a secure connection, prevent noise generation and increase walking comfort. Overview Dimensions:Length 80 mm | Width 25 mm | Height 6 mmJoint spacer 4 mmJoint spacer 7 mmMaterial:PP Polypropylene Recycled blackUV and weather resistantFastening type:Distance spacer for visible screw connections

The concealed decking connector TENI guarantees a very simple, fast and safe installation for modified, dimensionally stable wood species and compound decking boards with lateral cove.
The fastening system is characterized by two independently functioning fix and gliding point receptacles. The flexible and permanently elastic sliding point is automatically brought into position by the angled screw connection in the substructure. Natural dimensional changes per plank are compensated for via the pretensioning force generated. Swelling processes are not passed on to the neighboring plank - each decking plank works for itself - no chain reaction in the area.
The rigid fixed point ensures optimal positioning of the plank and enables safe installation without additional aids such as clamping tools or plank clamps. The 8 mm thick decking connector ensures perfect rear ventilation and structural protection of the components.
A safety device integrated in the base plate prevents the planks from being pushed out sideways.
If necessary, the planks can be replaced quickly and easily thanks to an integrated fold-out mechanism. The decking connector can be modified for the start and end planks. There is no need for a separate connector. TENI decking connectors can be installed on a wood or wood-like substructure and on the RELO T aluminum system rail.OverviewFastening: ConcealedType of fastening: Sliding and fixed pointJoint spacing: 6.0 mmDecking board: For modified, dimensionally stable wood types and compound planks with lateral covePlank exchange: Possible due to fold-out mechanismMaterial: POM polyoxymethylene, UV and weather resistantSpecial feature: Modification to start, end connector

for invisible fastening of decking boardsThe decking glider allows decking boards to be fastened indirectly / invisibly. This means that no screw heads are visible on the decking surface. This fastener is suitable for decking boards with side grooves as well as those without side grooves.The decking glider can be used either in combination with classic wooden substructures or with our modern aluminium system profile and HKP aluminium decking support system.AdvantagesIndirect/ invisible fastening solution
Supports constructive wood protection
Weather-resistant
Application notes
We recommend using the decking glide only with low-movement decking.
Low-movement decking includes the following types of wood, treatment methods and composite materials:
Larch
Douglas fir
Wood-polymer composites (WPC)
Thermowoods made from softwoods & hardwoodsAcetylated woodThe use of decking gliders is not recommended for woods with high bulk density and/or high swelling and shrinkage and only moderate stability (dimensional stability). This applies in particular to the wood species cumarú, ipé, massaranduba and robinia (false acacia).When selecting wood, particular emphasis should also be placed on good cut sorting (including sorting out boards with interlocking growth and so-called "fladder boards") as well as good conditioning (setting the equalisation moisture content) of the decking boards.Furthermore, a joint dimension between the boards that is matched to the type of wood, wood moisture and board width is essential for a durable construction. Information on this can be obtained from your timber dealer.The decking glide is available in two versions:Decking glideBoard width: 80 - 160 mmBoard thickness: 20 - 30 mmDecking glide MiniPlank width: 90 - 100 mmPlank thickness: ≥20 mmProcessing:To fasten the boards, the glides are first screwed to the underside of the boards and then to the substructure from above. This type of fastening avoids a direct connection between the decking boards and the substructure. The decking boards therefore have greater freedom of movement (via the decking glide).We recommend using two screws per decking glide for fastening the decking glide to the board and two screws for fastening the decking glide to the substructure.For the Mini decking glider, you should use two screws for fastening the Mini decking glider to the board and one screw for fastening it to the substructure.

Regardless of the board geometry this is implemented quickly with the DILA C decking connector. The height of the connector creates an optimal distance between the surface and substructure to prevent the formation of waterlogging. Each package contains the UNIA1 system screws 4.2 x 22 mm and 4.2 x 33 mm required for installation. 1 piece HELPO mounting aid and assembly instructions. Fixing: concealed systemFixing type: sliding and fixed pointJoint distance: selectableDecking board: For domestic and modified wood species 19 - 32 mmBoard replacement: possible when boards joints are over 6,0 mmMaterial: PA6 30 GF black plasticTension arm: Flexible designUNIA drilling capacity: ca. 3 mm thick AluminiumSpecial feature: start and end clip modification

It is essential for the durability of terraces is that the planks (decking) are infringed neither at the top nor at the lateral edges - exactly these important conditions are met the DielenFix®. His height of 6 mm ensures perfect constructive wood protection to the substructure and ensures optimally ventilating tete terrace - an essential criterion for the life of terraces. The enclosed SIHGA Bohrfix system screws for fastening to the substructure are specially manufactured without drilling for mounting on aluminum or wood and have a length of 29 mm. SIHGA DielenFix quantity calculation:To determine the amount required, we recommend the following auxiliary formula:Total linear meters of the substructure / plank width including gap x 2Using the example of a terrace with a 15 meter substructure, hallway width 144 mm, 6 mm groove:15 / 0.150 x 2 = 200 pieces    The use: fastened planks not visible screwed; produced, developed and patented in Austria gives elegant appearance and safety of the screw suitable for almost all types of wood reduces errors on site upon delivery of the material; thereby bringing time savings and reduced storage costs Made of SIHGAMID®, the fiberglass-reinforced plastic from the Space Exploration secured more durable than stainless steel, even when säurehältigen woods; is extremely strong, heat, frost and UV-resistant; no material fatigue Floorboards remain intact at all visible surfaces the woods are screwed from below, which gives longer shelf life and prevents putrefaction and the direct influence of weather like swelling and shrinkage of the wood from operations reduces the crack and fracture behavior of wood in these natural processes Choice of three screw lengths Possible use for all common hallway strengths 19-40 mm variable visible joint 0-15 mm, for each suitable builders Height, material thickness 6 mm for optimum aeration and ensures optimum constructive wood protection at DielenFix® II DF CS A4 screws are enclosed time-saving, convenient, accurate and matching SIHGAFIX® prevents rust and rust and stainless steel A4 BohrFix® for saltwater and chlorine environment Included SIHGAFIX® stainless, hardened stainless steel BohrFix® with drill bit and installation instructions no rust, no tearing or rupture of the screws; time-saving, convenient, accurate, all accessories accompanies SIHGA® TIP: MAGBIT® facilitates assembly For optimum adaptation to the type of wood of the boards or on the weathering situation of DielenFix® is produced in different materials or equipped with different fastening screws:Type DielenFix® II DF incl. BohrFix® stainless steelType DielenFix® II DF CS incl. BohrFix® stainless steel A4Type DielenFix® DF incl. BohrFix® stainless steel

The UNIA system screw is used to fasten metal or plastic parts to wood, wood-like materials and aluminum profiles up to a wall thickness of 3 mm.The tip, which is designed as a drilling unit, ensures a reduced splitting effect and less surface tension. Length: 17 - 47 mmDiameter: 4.2 mm and 4.8 mm Head: cylinder head Ø 5.8 mm Drill point: suitable for wood and aluminiumDrilling capacity: Aluminium with approx. 3 mm wall thickness Drive: TX 20Material: hardened stainless steel / stainless steel A4 1.4401with black surface coating DESCRIPTIONUNIA is a stainless steel self-drilling screw with a cylindrical head shape for fastening metal or plastic parts to wood, wood-like materials and aluminum profiles up to a wall thickness of 3.0 mm.The drill tip, which is designed as a drilling unit, ensures a reduced splitting effect and reduces surface tensions e.g. with screw connections on the back in element construction.APPLICATIONFor fastening concealed fastening systems such as TIGA, DILA, SUPRO, PLATA, LIGO and ZONA.The suitability and compatibility of the UNIA system screws with the component to be connected and their substructure may have to be determined by the plank or facade strip manufacturer / supplier.MATERIAL1.4006 / X12Cr13 / AISI 410 hardened stainless steelOptionally with black surface coating [black zinc plated]

The small aid for precise board spacing and exact pre-drillingIt has never been so easy to achieve such a visually pleasing result with the least effort.
Application: board spacing and drilling jigboard space: 5, 6, 7, 8 mmborder distance: 15, 20, 25 mm

Continuously protects the substructure and prevents surface friction noises from aluminium substructures.A self-protection and isolating band for substructures made of wood and aluminium. GUMO K protects the wooden substructure permanently against dirt and water retention and acts as a separation layer between two surfaces (hidden fastening clip and substructure) prone to friction.Length: 10 m RollWidth: 75 mmMaterial: butyl blackSpecial feature: self-adhesive, elasticized
